Key Features | Product Applications |
• Excellent thermoforming characteristics | • Merchandising/Point of Sale Displays |
• High Impact strength | • Vending machines |
• Easily die cut and punched | • Product Dispensers |
• Cost effective | • Medical Packaging |
• Printable | • Food Storage/Display’s |
• High Optical Quality | • Industrial Guards and Covers Slat-Wall Components |
Product Features
-High impact resistance
-Excellent transparency and gloss
-Excellent fire resistance. Low non-toxic smoke generation
-Outstanding thermoforming capabilities in deep draw forming
-Resistant to common cleaners used on point of purchase displays
Applications
-Used for a variety of commodity packaging, excellent transparency
-Used for vacuuming into various shapes of trays
-Used for hardware commodity packaging, the image of the inside of the display of goods, improve the grade of goods
Items | Test Method | Unit | Typical Value |
Property | |||
Specific Gravity | ASTM D792 | g/cm³ | 1.27 |
Rockwell Hardness | ASTM D785 | R-scale | 106 |
Moisture Absorption | ASTM D570 | % | 0.15 |
Mechanical | |||
Tensile Strength@Yield | ASTM D638 | Kgf/cm² | 496 |
Tensile Strength@Break 50mm/min(2 inch/min) | ASTM D638 | Kgf/cm² | 281 |
Elongation@Yield | ASTM D638 | % | 3.7 |
Elongation@Break | ASTM D638 | % | 136 |
Flexural Strength 1.27mm/min(2 inch/min) | ASTM D790 | 620 | |
Flexural Modulus 1.27mm/min(3 inch/min) | ASTM D790 | Kgf/cm² | 20800 |
Lzod impact Strength Notched@23℃ | ASTM D256 | J/m | 98 |
Thermal | |||
Heat Distortion Tempetature @0.45MPa(66 PSI) | ASTM D648 | ℃ | 77 |
Optical | |||
Haze | ASTM D1003 | % | ‹1.0 |
Transmittance | ASTM D1003 | % | 90 |
Refractive Index | ASDM D542 | / | 1.52 |
Flammability | |||
UL Flammability Classification @1.0mm thickness | UL 94 | / | |
UL Flammability Classification @1.5mm thickness | UL 94 | / | HB |
UL Flammability Classification @3.0mm thickness | UL 94 | / | V-2 |
Electric | |||
Dielectric Strength (short time, 500V/sec) | ASTM D149 | Kv/mm | 16 |
